GenesInk provides solutions for all your applications
in printed electronics.

GenesInk's nano-solutions help you to connect the objects of tomorrow. We help our customers to reduce the electronic circuits form factor and design new products for IoT, display, organic photovoltaics and LED, automotive.
delimiter image

Connected objects and
flexible electronics

The majority of applications that incorporate printed electronics are getting thinner in dimension and form factor is a key parameter. SmartInk conductive inks solutions open a new dimension for highly flexible electronic devices and connected objects by eliminating this technical road block.
GenesInk offers the ability to integrate electronic devices into most objects without having an impact on their shape or size: making them flexible, conformable, invisible while showing prolonged performance.

> Discover

Organic
electronics

Organic solar cells and organic LEDs show great potential due to their low production costs and mechanical flexibility. These characteristics open up a new range of solar cell applications. The HeliosInk product line covers most of the technologies that are required to manufacture thin, semi-transparent and flexible organic solar cells, from electrodes to charge transport layers.

> Discover

Transparent
conductive films

Transparent conductive films find applications in various fields in a wide range of products such as OPV, OLEDs, displays. With the emergence of new technologies such as flexible OPV or flexible displays, ITO films are no longer relevant since this material is brittle. GenesInk TranDuctive® is a wet solution printable with standard coating processes and compatible with plastic substrates thanks to its low drying temperature, enabling flexible device manufacturing.

> Discover

In-mold
Electronics

In-Mold Electronics eliminate additional weight and post-processing operations by allowing the electronic circuitry to be directly included during the molding cycle. It combines In-Mold Decorating technology with Printed Electronics. GenesInk’s SmartInk product line dedicated to In-Mold Electronics requires no compromise between formability and conductivity.

> Discover

More than 40 nano-solutions now available at ton scale plus the ability
to formulate custom design inks to meet your specific needs.

Nano-solution conductive inks based
on metal and metal oxides.

GenesInk offers a comprehensive range of conductive and semi-conductive inks for the IoT and printed electronics market. All printing methods are covered with specific formulations ; hassle-free and user-friendly formulations!
delimiter image
Image module
Image module

Join the IoT revolution using innovative and flexible applications with our conductive inks for downsized circuits and bright displays. SmartInk products are the right solutions for printing highly conductive and flexible circuits. SmartInk products are curable at very low temperatures and provide low sheet resistances.

> Discover

Image module
Image module

The right choice for more efficient and longer shelf life OPV and OLED devices. In addition to SmartInk conductive grids and bus bars, GenesInk patented HeliosInk solutions can be used for charge transport layer deposition in OPV and OLED cells, for both ETL and HTL layers.

> Discover

Image module
Image module

Considering the emergence of flexible screen technologies and flexible displays, ITO films are no longer relevant since this material is brittle. GenesInk proposes TranDuctive® as a wet solution printable with standard coating processes .
TranDuctive® inks are designed to improve processing cost in manufacturing ETL and transparent conductive layers for OPV, OLEDs and displays.

> Discover

Image module
Image module

In order to support the development of your new products, GenesInk is at your service by providing its expertise and equipment to your product development teams.
According to specifications and objectives defined with its customers, GenesInk is able to:
– Synthesize new nanomaterials
– Develop new ink formulations
– Optimize formulation processes and support your scale-up phases

> Discover

Creativity and respect commit
our team to delivering excellence.

Image icon

CREATIVITY

Our team of 12 + PhDs and engineers is dedicated to creating products that have a real added benefit to our customers: we listen to you and our formulations are meant to perfectly match your needs. We encourage our people to think outside the box and to find the right solution for the right application, offering you the opportunity to excel in your market.
Image icon

EXCELLENCE

We thrive on exceeding expectations, and our reward lies in the feedback of our customers. We aim to provide 100% customer satisfaction, and we carefully monitor and follow-up on each of our customer’s experience. We will make sure you are 100% satisfied with smaller devices.
Image icon

COMMITMENT

We are committed to producing non-toxic and non-CMR solutions in a fast and efficient way. Our production lead time is the best in the industry and we commit to delivering within in 10 days of order acknowledgement. “Speed” is one of GenesInk’s strengths.
Image icon

PEOPLE FOCUS & TALENT MANAGEMENT

As a growing company we emphasize interpersonal relationships and team spirit. This is how we build excellence and effectiveness, through a lean organization and a true sense of respect for each other.

GenesInk’s quality is guaranteed by global key
players in printed electronics.

Image module

Smaller, further, faster :
this is GenesInk !

GenesInk is the world’s industrial leader in industrial nano-solutions for IoT and printed electronics.
delimiter image

We offer more than 40 nano-solutions now available at ton scale, and we can formulate custom design inks to meet your specific needs.

Our industrial solutions are used for Integrated Smart Systems (flexible and printed devices for IoT), flexible and organic solar cells and OLEDs, touch panel displays.

By reducing the form factor of electronics, we help you to create new designs and smaller devices.

Our solutions serve multiple markets, including:

– Connected devices such as glasses, windows, watches, hearing aid, medical devices, office supplies
– RFID, LoRa, SigFox antennas
– Flexible PCBs and sensors
– Biosensors
– In-Mold Electronics for automotive and appliances
– Shielding
– ITO substrates
– Displays
– Solar cells (organics and perovskite),
– OLEDs

> Discover
